|Material:||PP Honeycomb Board/ Bubble Guard||Thickness:||8-15mm|
|Servo Motor:||Ankawa ,Japan||Line Track:||Shangyin, Taiwan|
|Besring:||NSK Nippon Ernsk||Speed:||3-5 Min/ Pcs|
Pallet PP Corrugated Board Machine,
Plastic Gaylord Pack Sleeve Machine,
Plastic Gaylord Corrugated Board Machine
PP Pallet Pack Sleeve Making Machine is to produce pallet sleeve pack. Used as middle sleeve for pallet and lid, such as conpearl box, KTP containers, pallet pack, pallet box, Megapack etc. The machine can process 8-15mm S type pp corrugated sheet, X type Profile PP Hollow Board , PP Flute Sheet, PP Sandwich Panel and PP Honeycomb Board or Bubble Guard material.
Now we have semi-automatic sleeve making machine and fully automatic sleeve making machine two type machine. Semi type use about 4-5 workers. Automatic use 2-3 workers. Automatic type production speed is about 3min per pcs.
|PP Pallet Sleeve Pack Making Machine|
|Processing Material||PP Honeycomb Board, Bubble Guard, PP Corrugated Sheet, X Type Profile PP Hollow Board, S Type PP Flute Sheet|
|Machine Speed||2-3 mins/ pcs Automatic, day upto 500 pcs|
|Operating Workers||3 workers per line automatic type|
|Machine Consists||Side Edge Sealing Machine (Round, Flat, Pointed shape)|
|Window/Door Opening Machine (Single or Double Station)|
|Sleeve Creasing Bending Machine (3 Creases or 6 Creases)|
|Butt Welding Machine Connection (One pcs or Two pcs)|
|Other Options||Saw Cutting Machine (cut board into accreate size)|
|Punching Hole Slotting Machine (single side or both side hole where to put lock)|
|Production Time||70-90 working days|
|Year Supply||20-30 lines|
|After ordering||1 year warranty, Train Worker, Online testing|
The equipment includes side edge sealing machine, hole sloting machine, open door/window machine, 3/6 creasing machine and final jointing machine. Manully or Auto type two kind machine for choosing. After our testing , it can process any material from any machines.
PP Pallet Sleeve Making Machine designed to process bubble guard, pp honeycomb board, S type pp corrugated sheet and X type pp hollow board for plastic sleeve. It can process thickness 8mm-15mm material and width upto 1300mm or 1500mm.
Plastic Sleeve Production Machine includes PLC control system(SIEMENS), Automatic feeding unit, Edge trimming unit, Round/Flat/Pointed Edge sealing unit, Hole Slotting/Punching unit, Die-cutting unit, Creasing unit(hinge making), Stacking unit and hot-melt welding unit(butt fusion welder). Raw board saw cutting is optional.
All parts can be customed.
Machine Video Link: https://www.youtube.com/watch?v=9l54rjvr75U
